description

CUSTOM LOW-LATENCY DRIVERS

The Fender Quantum LT 2 uses proprietary drivers that deliver class-leading converter latency performance, providing a responsive, natural recording experience that feels immediate to the performer.

MAX-HD MIC PREAMP

The MAX-HD mic preamp delivers a massive +75 dB of gain to ensure clean, transparent capture with any microphone, from delicate condensers to gain-hungry ribbon mics.

FENDER-DESIGNED INSTRUMENT INPUT

Purpose built input tuned by Fender delivers plug-and-play clarity for guitars, basses, and other instruments — no fiddling with impedance or gain staging required.

REMOTE SOFTWARE INTEGRATION

Control your direct-monitoring mixer from Fender Studio Pro or Fender Universal Control on your computer or supported mobile device — even when you’re away from the interface.

KEY FEATURES

•2x2 USB audio interface with custom low-latency drivers for responsive recording

•MAX-HD mic preamp with 75 dB gain range — perfect for any microphone

•Fender-designed instrument input for guitars, basses, and more

•Balanced TRS outputs and powerful headphone output for monitoring flexibility

•Integrated line input for connecting external gear

•Software integration with Fender Studio Pro and Universal Control for remote mix control

•Loopback audio for streaming and monitor mixes

•Standalone “Mixer Mode” for use as an analog mixer without a computer

•Built-in My Fender access for registration, setup, and support

TECHNICAL SPECIFICATIONS

AD / DA CONVERSION

Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz

Bit Depth 24-bit

INSTRUMENT INPUT

Connector Type ¼-inch Female

Maximum Level +12dBu

Frequency Response 20 Hz to 20 kHz

Dynamic Range 114 dB

THD+ N 0.001%

Input Impedance 1M Ohms

MICROPHONE INPUTS

Connector Type XLR/TRS Combo

Maximum Level +14 dBu

Input Impedance 1600 Ohms

Gain Range 0 to +75 dB

Frequency Response 20 Hz to 20 kHz

Dynamic Range 115 dB

THD+ N 0.001%

EIN -128.6 dBu

Phantom Power 48V

LINE INPUTS

Connector Type Combo-style, XLR / TRS

Max input level +15 dBu

Impedance 10K Ohms

Frequency Response 20 Hz to 20 kHz

Dynamic Range 115 dB

THD+ N 0.001%

Gain Range 0 to +26 dB

MAIN OUTPUTS

Connector Type ¼-inch Female, TRS

Max Output Level +15 dBu (Balanced)

Frequency Response 20 Hz to 20 kHz

Dynamic Range 115 dB

THD+ N 0.001%

Trim Range -∞ dB to 0 dB

HEADPHONE OUTPUTS

Connector Type ¼-inch Female, TRS

Maximum Power (56Ω load)

46 mW/channel

Frequency Response 20 Hz to 20 kHz

Dynamic Range 114 dB

THD+ N 0.001%

Trim Range -∞ dB to 0 dB

PRODUCT DIMENSIONS

Length 3.5" (88mm)

Width 5.5" (139.7mm)

Height 1.75" (44.45mm)

Weight 1.125 lbs (.51kg)
