description

TWO MAX-HD MIC PREAMPS



The LT 4 expands flexibility with two transparent, low-noise MAX-HD mic preamps offering +75 dB of gain, perfect for small ensembles, duos, or multi-source recording.



CUSTOM LOW-LATENCY DRIVERS



Record and monitor in real time with drivers that outperform typical USB interfaces, making the LT 4 a responsive tool for serious creators.



LOOPBACK AUDIO



Easily mix in system audio with your session for podcasting, streaming, and content creation, no extra hardware required.



REMOTE SOFTWARE INTEGRATION



Control your direct-monitoring mixer from Fender Studio Pro or Fender Universal Control on your computer or supported mobile device, even when you’re away from the interface.



KEY FEATURES



•4x2 USB audio interface with custom low-latency drivers •Two MAX-HD microphone preamps with 75 dB gain range



•Dual Fender-designed instrument inputs for guitars, basses, and more •Balanced TRS outputs and powerful headphone output •Integrated line inputs for connecting external gear



•Remote direct monitoring control via Fender Studio Pro and Universal Control



•Loopback functionality for streaming and content creation •Standalone “Mixer Mode” for simple, computer-free mixing •Built-in My Fender access for account setup, software downloads,



and support

TECHNICAL SPECIFICATIONS



AD / DA CONVERSION



Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz



Bit Depth 24-bit



INSTRUMENT INPUT



Connector Type ¼-inch Female



Maximum Level +12dBu



Frequency Response 20 Hz to 20 kHz



Dynamic Range 114 dB



THD+ N 0.001%



Input Impedance 1M Ohms



MICROPHONE INPUTS



Connector Type XLR/TRS Combo



Maximum Level +14 dBu



Input Impedance 1600 Ohms



Gain Range 0 to +75 dB



Frequency Response 20 Hz to 20 kHz



Dynamic Range 115 dB



THD+ N 0.001%



EIN -128.6 dBu



Phantom Power 48V



LINE INPUTS



Connector Type Combo-style, XLR / TRS



Max input level +15 dBu



Impedance 10K Ohms



Frequency Response 20 Hz to 20 kHz



Dynamic Range 115 dB



THD+ N 0.001%



Gain Range 0 to +26 dB



MAIN OUTPUTS



Connector Type ¼-inch Female, TRS



Max Output Level +15 dBu (Balanced)



Frequency Response 20 Hz to 20 kHz



Dynamic Range 115 dB



THD+ N 0.001%



Trim Range -∞ dB to 0 dB



HEADPHONE OUTPUTS



Connector Type ¼-inch Female, TRS



Maximum Power (56Ω load)



46 mW/channel



Frequency Response 20 Hz to 20 kHz



Dynamic Range 114 dB



THD+ N 0.001%



Trim Range -∞ dB to 0 dB



PRODUCT DIMENSIONS



Length 3.5" (88mm)



Width 7" (178mm)



Height 1.75" (44.45mm)



Weight 1.8. lbs (.82kg)
